• 100 amp alternator
• 18 gallon fuel tank
• 4-wheel drive
• 5350# GVWR (2800 front/2700 rear), springs (2800 front/2700 rear), axles (2800 front/2900 rear)
• Aluminized stainless steel exhaust system
• Front/rear stabilizer bars
• Torsion bar front suspension

• 4-wheel anti-lock brakes
• Driver & front passenger airbags
• Dual high/low note electric horn

4.3L (262) SFI V6 (VORTEC) ENGINE

• (STD)

4-SPEED ELECTRONICALLY-CONTROLLED AUTOMATIC TRANSMISSION W/OD

• (STD)

• 3.42 Axle Ratio
• 4-Wheel Disc Brakes
• ABS brakes
• Air Conditioning
• AM/FM radio
• Bumpers: body-color
• Driver door bin
• Dual front impact airbags
• Front anti-roll bar
• Front beverage holders
• Front Bucket Seats
• Front wheel independent suspension
• Fully automatic headlights
• Liftgate/Liftglass Body
• Passenger door bin
• Passenger vanity mirror
• Power steering
• Rear anti-roll bar
• Roof rack
• Split folding rear seat
• Tachometer
• Variably intermittent wipers
• Voltmeter

• Vehicle
• Rear Door Type: Liftgate
• Mileage
• EPA Fuel Economy Est - City (MPG): 16
• EPA Fuel Economy Est - Hwy (MPG): 20
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 690
• Maximum Alternator Capacity (amps): 100
• Maximum Alternator Watts: - TBD -
• Cooling System
• Total Cooling System Capacity (qts): 11.7
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 2800
• Gross Axle Wt Rating - Rear (lbs): 2700
• Curb Weight - Front (lbs): 2335
• Curb Weight - Rear (lbs): 1753
• Gross Vehicle Weight Rating Cap (lbs): 5350
• Gross Combined Wt Rating (lbs): 9500
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 3500
• Dead Weight Hitch - Max Tongue Wt. (lbs): 350
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 5000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 600
• Suspension
• Suspension Type - Front: Torsion Bar
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 2800
• Spring Capacity - Rear (lbs): 2700
• Axle Type - Front: Independent Driving
• Axle Type - Rear: Semi-Floating
• Axle Capacity - Front (lbs): 2800
• Axle Capacity - Rear (lbs): 2900
• Axle Ratio (:1) - Front: 3.42
• Axle Ratio (:1) - Rear: 3.42
• Shock Absorber Diameter - Front (mm): 46 de Carbon
• Shock Absorber Diameter - Rear (mm): 32 Load-Leveling
• Stabilizer Bar Diameter - Front (in): 1.30
• Stabilizer Bar Diameter - Rear (in): 0.75
• Brakes
• Brake Type: Power
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 10.82 x 1.14
• Rear Brake Rotor Diam x Thickness (in): 11.6 x 0.79
• Tires
• Front Tire Order Code: QBF
• Rear Tire Order Code: QBF
• Front Tire Size: P235/70R15
• Rear Tire Size: P235/70R15
• Spare Tire Size: P235/70R15
• Front Tire Capacity (lbs): 1643
• Rear Tire Capacity (lbs): 1643
• Spare Tire Capacity (lbs): 1643
• Revolutions/Mile @ 45 mph - Front: 743
• Revolutions/Mile @ 45 mph - Rear: 743
• Revolutions/Mile @ 45 mph - Spare: 743
• Wheels
• Front Wheel Size (in): 15 x 7
• Rear Wheel Size (in): 15 x 7
• Spare Wheel Size (in): 15 x 7
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Power
• Steering Ratio (:1), On Center: 16.0
• Steering Ratio (:1), At Lock: 13.0
• Turning Diameter - Curb to Curb (ft): 39.5
• Turning Diameter - Wall to Wall (ft): 41.2
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 18.0
• Fuel Tank Location: Forward of Rear Axle
• Exterior Dimensions
• Wheelbase (in): 107.0
• Length, Overall w/rear bumper (in): 183.8
• Width, Max w/o mirrors (in): 67.8
• Height, Overall (in): 64.4
• Overhang, Front (in): 34.8
• Overhang, Rear w/bumper (in): 42.0
• Ground to Top of Load Floor (in): 29.5
• Ground Clearance, Front (in): 8.3
• Ground Clearance, Rear (in): 7.5
• Rear Door Opening Height (in): - TBD -
• Rear Door Opening Width (in): - TBD -
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Seat 1 (in): 74.6
• Cargo Area Length @ Floor to Seat 2 (in): 40.5
• Cargo Area Width @ Beltline (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): 38.1
• Cargo Box (Area) Height (in): 34.6
• Cargo Volume to Seat 1 (ft³): 74.1
• Cargo Volume to Seat 2 (ft³): 37.3
• Interior Dimensions
• Passenger Capacity: 5
• Front Head Room (in): 39.5
• Front Leg Room (in): 42.4
• Front Shoulder Room (in): 57.1
• Front Hip Room (in): 53.6
• Second Head Room (in): 38.1
• Second Leg Room (in): 36.3
• Second Shoulder Room (in): 57.2
• Second Hip Room (in): 51.3
• Summary
• Vehicle Name: GMC Envoy
• Body Style: 4 Door
• Body Code: TB4
